Forklift Drive Axle

Forklift Drive Axle - A forklift drive axle is a piece of equipment that is elastically fastened to a vehicle framework with a lift mast. The lift mast is connected to the drive axle and could be inclined around the drive axle's axial centerline. This is done by no less than one tilting cylinder. Forward bearing parts together with back bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing parts. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is affixed to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the swiveling axis to the axial centerline.

Unit H35, H40, and H45 forklifts, that are made by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle frame itself. The drive axle is elastically affixed to the frame of the forklift utilizing many various bearings. The drive axle comprise tubular axle body together with extension arms connected to it and extend backwards. This kind of drive axle is elastically affixed to the vehicle framework using rear bearing parts on the extension arms along with frontward bearing tools located on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the forklift from the other bearing tool in its respective pair.

The braking and drive torques of the drive axle on this unit of lift truck are sustained by the extension arms through the back bearing components on the frame. The forces generated by the lift mast and the load being carried are transmitted into the floor or street by the vehicle frame through the front bearing parts of the drive axle. It is essential to make certain the components of the drive axle are configured in a rigid enough method so as to maintain strength of the lift truck truck. The bearing parts can reduce small road surface irregularities or bumps during travel to a limited extent and give a bit smoother operation.
