Forklift Starters and Alternators - Today's starter motor is typically a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid mounted on it. When current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is located on the driveshaft and meshes the pinion utilizing the starter ring gear that is seen on the engine flywheel.
As soon as the starter motor starts to turn, the solenoid closes the high-current contacts. As soon as the engine has started, the solenoid consists of a key operated switch which opens the spring assembly in order to pull the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just a single direction. Drive is transmitted in this particular way via the pinion to the flywheel ring gear. The pinion continuous to be engaged, for example since the driver did not release the key once the engine starts or if the solenoid remains engaged since there is a short. This actually causes the pinion to spin separately of its driveshaft.
This aforesaid action prevents the engine from driving the starter. This is actually an important step in view of the fact that this kind of back drive will allow the starter to spin really fast that it will fly apart. Unless adjustments were made, the sprag clutch arrangement would preclude utilizing the starter as a generator if it was utilized in the hybrid scheme mentioned prior. Normally a regular starter motor is meant for intermittent utilization which will preclude it being utilized as a generator.
The electrical components are made so as to operate for approximately thirty seconds to be able to prevent overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical components are intended to save cost and weight. This is truly the reason nearly all owner's instruction manuals used for automobiles recommend the driver to stop for a minimum of ten seconds after every ten or fifteen seconds of cranking the engine, whenever trying to start an engine that does not turn over at once.
The overrunning-clutch pinion was launched onto the marked during the early 1960's. Previous to the 1960's, a Bendix drive was utilized. This particular drive system works on a helically cut driveshaft that has a starter drive pinion placed on it. Once the starter motor begins spinning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear enables the pinion to surpass the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.
During the 1930s, an intermediate development between the Bendix drive was developed. The overrunning-clutch design that was developed and introduced during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights within the body of the drive unit. This was better because the typical Bendix drive utilized to be able to disengage from the ring once the engine fired, even though it did not stay functioning.
The drive unit if force forward by inertia on the helical shaft as soon as the starter motor is engaged and starts turning. Then the starter motor becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, like for example it is backdriven by the running engine, and afterward the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement could be avoided prior to a successful engine start.
