Throttle Body for Forklift
Forklift Throttle Body - Where fuel injected engines are concerned, the throttle body is the part of the air intake system which regulates the amount of air which flows into the engine. This particular mechanism works in response to operator accelerator pedal input in the main. Generally, the throttle body is situated between the intake manifold and the air filter box. It is usually fixed to or positioned next to the mass airflow sensor. The largest part inside the throttle body is a butterfly valve called the throttle plate. The throttle plate's main function is to be able to regulate air flow.
On nearly all cars, the accelerator pedal motion is transferred via the throttle cable, hence activating the throttle linkages works to move the throttle plate. In vehicles with electronic throttle control, also called "drive-by-wire" an electric motor controls the throttle linkages. The accelerator pedal connects to a sensor and not to the throttle body. This sensor sends the pedal position to the ECU or Engine Control Unit. The ECU is responsible for determining the throttle opening based upon accelerator pedal position together with inputs from different engine sensors. The throttle body consists of a throttle position sensor. The throttle cable is attached to the black portion on the left hand side which is curved in design. The copper coil situated close to this is what returns the throttle body to its idle position as soon as the pedal is released.
The throttle plate rotates inside the throttle body every time the driver presses on the accelerator pedal. This opens the throttle passage and allows much more air to flow into the intake manifold. Typically, an airflow sensor measures this change and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors in order to generate the desired air-fuel ratio. Often a throttle position sensor or otherwise called TPS is attached to the shaft of the throttle plate to provide the ECU with information on whether the throttle is in the wide-open throttle or also called "WOT" position, the idle position or anywhere in between these two extremes.
In order to control the minimum air flow while idling, various throttle bodies may include valves and adjustments. Even in units that are not "drive-by-wire" there will normally be a small electric motor driven valve, the Idle Air Control Valve or IACV which the ECU utilizes to control the amount of air that can bypass the main throttle opening.
In various automobiles it is common for them to contain one throttle body. To be able to improve throttle response, more than one could be utilized and attached together by linkages. High performance cars like the BMW M1, along with high performance motorcycles such as the Suzuki Hayabusa have a separate throttle body for each and every cylinder. These models are called ITBs or likewise known as "individual throttle bodies."
A throttle body is similar to the carburetor in a non-injected engine. Carburetors combine the functionality of the throttle body and the fuel injectors into one. They operate by blending the air and fuel together and by controlling the amount of air flow. Vehicles which have throttle body injection, which is referred to as CFI by Ford and TBI by GM, put the fuel injectors inside the throttle body. This enables an old engine the possibility to be converted from carburetor to fuel injection without really changing the design of the engine.
